SPECIFICATION:
– Wingspan: 1,635 mm (64.4 in).
– Length: 2.260 mm(89.0in)
– Weight: 12.4 kg (27 lbs).
– Wing area: 79.3 dm2.
– Wing loading: 156.3 g/dm2.
– Wing type: Naca Airfoil.
– Servo mount: 37mm x 16mm and 41mm x 21mm.
– Gear type: Electric Retract Gear with oleo struts (included) and controller box (included).
Parts listing required (not included):
– Radio: 8 channels minimum.
– Servo: 7 (HV high torque servos) , size: (35 x 15)mm , (2 HV high torque servos, size 40mm x 20mm torque : 35-42kg/cm Elevator)
– Engine: Turbine Jet Engine with thrust 13kg (not included).
Recommended Battery set up (not included):
– Battery receiver: 2S- 7.4V 2,200mAh – 3,200mAh.
ALL BALSA – PLY WOOD CONSTRUCTION.
COVERED IN A HEAT-SHRINK FILM WITH PRINTED
(BH-185)
SKU | BH-185 |
Brand | BLACK HORSE AIRCRAFT |
